Wholesale NOYAFA NF-521 Thermal Imager Camera Manufacturer
Wholesale NOYAFA NF-521 Thermal Imager Camera Manufacturer
Temperature measurement range | -10~400℃ |
Basic accuracy | ±2% or ±2.0℃ |
Emissivity | adjustable 0.1~0.99 |
Measuring resolution | 0.1℃ |
Response time | 150ms |
Spectral band | 8~14um |
Thermal imaging technique | |
Thermal imaging resolution | 32*32(1024 pixels) |
Electronic shutter | No |
Visible light camera | 2 mega pixels |
Display resolution | Thermal imaging, thermal mixing, digital camera |
Color palettes | Ironbow,iridescence ,Grayscale |
Infrared spectral bandwidth | 8~14μm |
FOV | 33° horizontal |
IFOV | 18 mrad |
Thermal imaging sensitivity | 150mk |
Frame rate | ≤9Hz |
Image format | BMP |
General parameters | |
Monitor | 2.4 & rdquo; TFT LCD |
Display resolution | 320*240 pixels |
Battery | 3.7V/2600mAh |
Automatic shutdown function | Yes |
Certification | CE |
SD card | 8GB TF card |
Working temperature | -10℃~45℃ |
Drop proof | 2m |
Standard accessories | manual, USB cable, 8GB micro TF card |
Customized support: | OEM, ODM, OBM |
Our main focus now is to enhance our core competitiveness. It is widely known that by utilizing those technologies, NOYAFA pipeline blocking meter NF-5130 30m factory wholesale price effective diagnosis of pipeline blocking quality can be guaranteed.It is manufactured to be used in the field(s) of Other Tools.
Main function:
1. 2-megapixel white lens
2. 2.4 TFT LCD Display
3. Temperature testing range: -10°C ~ 400°C
4. 32×32 pixel resolution, 33° Field of View
5. Merging visible and infrared image display
6. Chargeable Li-ion battery for power supply.
Product Manual
Product Manual
NF-521 Thermal Imager
